- For Hand-Arm vibration to ISO5349, whole-body vibration to ISO2631 and ship vibration to ISO 6954
- Acceleration, velocity and displacement ranges for machine vibration
- Display of running and interval RMS, maximum RMS (MTVV), vibration dose value (VDV), vector sum, peak and maximum peak value
- Fourth channel for SEAT measurements at driver seats
- 3-channel FFT for the detection of main frequencies
- TEDS support for automatic sensor detection
- Memory for saving measurements by keypress
- Data logger function for RMS or peak values
- USB interface for data transfer to a PC
- Excel macro for the calculation of daily exposure A(8) and report generation
- Compact design
- Simple operation
| Measuring inputs | 4 Low Power IEPE inputs with TEDS for sensors with 8 to 1200 mV/g |
| Human vibration weighting filters | Wb, Wc, Wd, Wh, Wj, Wk and Wm to ISO8041 |
| Band filters | Human vibration: 0.4 - 100 Hz; 6.3 - 1259 Hz Acceleration: 0.1 - 1500 Hz; 1 - 1000 Hz Velocity: 1 - 100 Hz; 2 - 1000 Hz; 10 - 1000 Hz Displacement: 5 - 250 Hz |
| Frequency analysis (FFT) | 125 lines for X/Y/Z, peak spectrum of acceleration |
| Data memory | 10000 manually saved measurements, 100 log files of 32000 measurements each, 1000 FFTs, each with date, time and comment |
| Display | OLED, 128 x 160 pixels, colored |
| Batteries | 3 accumulators HR03 or alkaline cells LR03 (AAA), 10 -14 hours operation |
| Recommended sensors | Hand-Arm: KS963.10 Whole-body: KS963SV Machine vibration: KS903-100 Ship vibration: KS823B 4th channel (A): KS78B100 |
| VM31 accessory kits |
Whole-body: VM31-HAWB Hand-Arm/whole-body: VM31-HAWB Machine vibration: VM31-M |
